| Form Factor | U.2 2.5-inch |
| Interface | PCIe 4.0 1x4 |
| NVMe Protocol | NVMe 1.4 |
| NAND Flash | 3D TLC |
| Available Capacity | 1.6TB | 1.92TB | 3.2 TB | 3.84 TB | 6.4 TB | 7.68 TB | 15.36TB |
| Average Power Consumption (Idle, Active) | 7.5 W (idle) , 18 W (Active) |
| Weight (g) | < 182 g |
| TRIM | Supported |
| Power Failure Protection | Supported |
| Chip Failure Protection | Supported |
| Reliability | Meantime between failures (MTBF): 2.5 million hours;
Annual failure rate (AFR): ≤ 0.35% ;
Uncorrectable bit error rate (UBER): 10^-18 |
| Temperature | Non-operational: –40ºC to 85ºC (–40°F to 185ºF);
Operational: 0ºC to 83ºC（32°F to 181.4ºF） |
| Data Retention (Power-off) | 3 months at 40ºC (104ºF） |
| Supported Servers | Servers supporting U.2 NVMe SSD disks |
| Certifications | China: RoHS
Europe: WEEE, RoHS, REACH, and CE
Northern America: NRTL
UK: UKCA
Japan: VCCI
Canada: IC
Australia: RCM
Member States of IEEE: CB |
eKitStor Xtreme 300P PCIe 4.0 ...
